6061 Aluminium Stair Nosing Edge Trim , T5 Non Slip Extruded Aluminum Nosing

Basic Information
Place of Origin: China
Brand Name: Ruicheng
Model Number: Aluminum Stair Nosing-001
Price: To Be Negotiated
Packaging Details: carton/poly bag/shrink film/pallet/customized
Delivery Time: 15-20 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 100000 pieces per month
Detail Information
Material: Aluminum Type: Stair Part
Thickness: 0.35mm To 3mm Or Customized Length: 2.4/2.5/2.7/3m
Color: Sliver/customization Surface Treatment: Anodized,polished,mill Finish
Height: 5.5/6/7/8/8.3/8.5mm/Custiomized Product Name: Aluminum Stair Nosing
High Light:

6061 Aluminium Stair Nosing Edge Trim


T5 Aluminium Stair Nosing Edge Trim


T5 extruded aluminum nosing

Product Description

Non Slip Aluminium Stair Nosing Edge Trim Metal Staircase Protector



Wide grooved stair profile with rubber. These are excellent quality anodised aluminium stair noising. This profile protects the edges of stair steps covered with ceramic tiles, wood or laminates. Rubber inserts consitute anti-skidding protetction .

It can be mounted by means of durable assembly glue or a brand type. Each stair nosing come pristine in manufacture packing with screws and is perfored.

The unquestionable advantage of these Aluminium Stair Strips is an invisible method of mounting to the base. Screw Fix - First remove kindly the anti-slip rubber insert - Then simply drill holes - Next screw the screws into the stair, through the holes already present on your stair nosing.



Extruded Aluminum Nosings are manufactured with a base container of 6061-T5 extruded aluminum filled with an abrasive mixture of aluminum oxide and silicon blend, compacted and bonded by 100% solid epoxy. Extrusions are designed for installation during a new concrete pour and barrier free products are offered for installation on sheet metal pan treads.

Manufactured in lengths up to 24′-0”, nosings are offered cut-to-length to save on costly field labor. Stock colors are black or yellow, with a wide range of optional colors available on special order. If specified, factory tape is applied to the abrasive surface to provide protection during installation.



Stair-nosing profiles are resistant to most chemicals encountered in tiled environments. In special cases, the suitability of a proposed type of material must be verified based on the anticipated chemical, mechanical, and/or other stresses. Exceptions and special consider-ations are listed below.

Aluminum profiles must be tested to verify their suitability if chemical stresses are anticipated. Cementitious materials, in conjunction with moisture, become alkaline. Since aluminum is sensitive to alkaline substances, exposure to the alkali (depending on the concentration and duration of exposure) may result in corrosion (aluminum hydroxide formation). Therefore, it is important to remove mortar or grout residue from visible surfaces. In addition, ensure that the profile is solidly embedded in the setting material and that all cavities are filled to prevent the collection of alkaline water.





Profile Aluminum extrusion/Stainless steel/PVC
Thickness 0.5-1.5mm
Length 1M/2M/2.5M/2.6M/2.8M/3M
Surface treatment
(Stainless Steel)
Brushed(SSB)/ Electrophoresis/2B/BA/Mirror Polish(MP)/Satin
stainless steel TG
Surface treatment
(aluminum extrusion)
Electrophoresis/Anodized/Power coating/Wood grain transfer
Colour Silver, Gold, Black,any solid color are available;
Certificate CE/SGS
Punching Hole Shape Square/ Round/ Triangle or Customized.
Application1 transition strip carpet to tiles,stair nosing,nosing strips,edge trim protection,
transition expansion joint cover strip,tile Corner trim for subway tiles,shower tiles 45MM aluminum stair nosing,anti slip rubber strip,tile trim Corner guard outside,tile
edge trim on shower outside Corner wall and curb,smart tiles finishing edge.
Application2 tile edge trim in tile accessoriessection,edge designs for backspashes,smooth finish
silver aluminum external edge tile trim,tile transition pieces for floor and decor,
straight edge tile trim ,L shaped tile trim ,floor cover edge of unglazed,square edge
tile trim.
Application3 box edge tile trim,edging tile trim,edging tile trim,double rail edging profile for
bonding tile,edge protection profile for outside corners,tiles edges on walls ,round
edge tile trim black,tile edge and corner trim,trim to floor tiles.



6061 Aluminium Stair Nosing Edge Trim , T5 Non Slip Extruded Aluminum Nosing 06061 Aluminium Stair Nosing Edge Trim , T5 Non Slip Extruded Aluminum Nosing 16061 Aluminium Stair Nosing Edge Trim , T5 Non Slip Extruded Aluminum Nosing 2
