Waterproof Aluminium LED Strip Light Profile 1.8mm Thickness Recessed

Basic Information
Place of Origin: China
Brand Name: Ruicheng
Model Number: Aluminium Led Profile-010
Price: To Be Negotiated
Packaging Details: carton/poly bag/shrink film/pallet/customized
Delivery Time: 15-20 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 100000 pieces per month
Detail Information
Material: Aluminum Thickness: 1.8mm Or Customized
Surface Treatment: Anodized,polished,mill Finish Height: 6/7.5/8/8.3/8.5mm/Custiomized
Product Name: Aluminium Led Profile Temper: T3-T8
Grade: 6000 Series Shape: Square,Round
High Light:

Waterproof Aluminium LED Strip Light Profile


1.8mm Aluminium LED Strip Light Profile


aluminium housing for led strip lights

Product Description

Floor Corner Aluminium Led Profile Lighting Strips Waterproof Decorative Extruded



Ruicheng Aluminium offers more than 100 types of aluminium extrusions and multiple options for each, enhancing design flexibility in any lighting project. This gives architects and designers more flexibility and more ways to realise their vision.We supplies aluminium extrusions for under-bench lighting, corridor lighting, and office and reception lighting. Extrusions are available for recessed, suspended and surface mounted installation to suit virtually any lighting application.The LED extrusions take lighting design to the next level with options allowing for lights to be recessed into walls, ceilings and even in-floor.Pendant lighting models can also be customised at varying lengths to create amazing 3D effects for reception areas, breakout rooms or meeting spaces.Comprising of suspended up/down lighting extrusions, plaster-in trimless extrusions, suspended tubular extrusions, recessed flanged extrusions and surface mounted arched extrusions among many more, Ruicheng’s aluminium extrusion range is easy to install and can be supplied cut-to-length.



Beside the main reason of protecting and extending the longevity of LED strip lights, alu extrusions bring you many benefits. Here’s a short list of the most important ones:

  • Heat absorption – as any other light source, LED tape generates heat (although far less than incandescent lights) which can be absorbed by the aluminium profile, protecting your wood or wood-like surfaces from a fire hazard.
  • Firm placement – although sticky, LED strip won’t hold in place forever – the glue will weaken in time. With an aluminium profile, you can permanently mount it in the desired location without worrying it’ll fall off.
  • Light directing – a LED profile is an easy way to direct the light – just choose the right angled one for your project and shine it just where you want it.
  • Reflection consistency – a profile’s diffuser creates a consistent dot free reflection. This is especially impotent while using LEDs in conjunction with highly reflective surfaces (e’g., tiles or worktops), which tires eyes quickly.
  • Easier cleaning – using a LED extrusion is an easy way to keep your light source nice and clean as you won’t catch the diodes encased within with your duster.



Extrusions can be fixed in place using countersink screws, straight into the extrusion. Alternatively, you can purchase fixing brackets if you prefer. These can be attached in place, and once they are in position, your extrusion can be clipped onto them.

  1. Ensure the channel is cut to the length you require and screw the mounting bracketsinto the surface of choice at 1m intervals.
  2. Peel the adhesive backing off the run of LED tape and stick the length of the tapeinto the channel.
  3. Clip the diffuser onto the channel.
  4. Insert the end clips onto each end of the profile, ensuring the 2 core cable is threadthrough the hole in one of the end caps. This cable will attach to the driver or powersource.
  5. Press the profile firmly into the mounting brackets so they click into place.





Product Name LED Aluminum Profile
Material Aluminum Alloy
cover PC Diffuser
Accessories PC end caps, Metal clips
Surface Treatment Anodized silver. other colors on request
Standard Length 1/2m(Customized length is also available)
Installation Recessed
Warranty 5 years
Delivery Time 3-6 working days for sample
our Advantage Design according to your decoration plan

Waterproof Aluminium LED Strip Light Profile 1.8mm Thickness Recessed 0Waterproof Aluminium LED Strip Light Profile 1.8mm Thickness Recessed 1Waterproof Aluminium LED Strip Light Profile 1.8mm Thickness Recessed 2
