Antifingerprint Aluminium Panel Trim , 3m Aluminium Square Edge Tile Trim

Basic Information
Place of Origin: China
Brand Name: Ruicheng
Model Number: Aluminum Panel Trim-002
Price: To Be Negotiated
Packaging Details: carton/poly bag/shrink film/pallet/customized
Delivery Time: 15-20 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 100000 pieces per month
Detail Information
Material: Aluminum Tile Accessory Type: Tile Trims
Thickness: 2mm/customization Length: 3m/customization
Color: Golden/sliver Surface Treatment: Anodized,polished
Height: 7.8/8.3/8.5mm/Custiomized Product Name: Aluminium Panel Trim
High Light:

Antifingerprint Aluminium Panel Trim


3m Aluminium Panel Trim


aluminium square edge tile trim

Product Description

Square End Cap Aluminium Panel Trim Wall Tile Corner Protection UV Board Decoration




Surface Finish:

• Natural anodised finish

• Mill (untreated) finish

Please contact us if you require a surface finish that is not shown.

N.B. Jig or clamp marks on anodised items can be unsightly, and are normally positioned up to 50mm in from each end. When aesthetic considerations apply, these markings should be cut away.





Wet Wall Trim, Shower Wall Trim, Aluminium, Bright Silver, End Cap Trim, Internal Corner Shower Trim, External Corner, H Join, Angle Trim, Extruded Angle, Wet Room





Step 1. Carefully unpack the profiles and ensure they are in good condition & fit for purpose.

Step 2. If the items have been anodised, any unsightly jig marks should be cut away from the extreme ends, before fixing commences.

Step 3. Select suitable quality fixings that are appropriate for use with the intended fixing surface.

Step 4. Carefully drill csk. holes through the v-shaped groove, located in the extended fixing flanges of the wall board profiles.

Step 5. After fixing into position, check that the profiles are safely secured to the supporting background surface.

Step 6. To ensure stability, make sure the wall boards are fully inserted into the retaining channels of the profiles.

Cleaning and Maintenance: All that is normally required to maintain the appearance and prevent the build-up of surface contaminants on the visible surfaces is an occasional wipe over with a soft, dry cloth. Any liquids being used for cleaning purposes must be applied in small amounts to a soft cloth. Grease or oil deposits can be removed with organic solvent such as white spirit, followed by wiping over with a mild diluted detergent and rinsing with cold clean water. Dry off with a soft cloth. It is important that abrasive cleaners or scourers are not used on the aluminium surface, as otherwise, damage may occur.





Product Name Aluminium Panel Trim
Material Metal, Aluminium
Color Silver, Golden, Rose Gold, Black Titanium, Red Copper, Champagne, Bronze, Sapphire, Customized color
Surface treatment 8K mirror, Hairline ,Shiny, Matt, Etching, Embossing,Anti-fingerprint , Or customized
Type U channel, L shape, T shape , customized shape
Thickness 0.4mm~3.00mm, or customized
Length 2.44/3.05/4m per piece, or customized

1.Wall corner protection , anti-collision

2.Protecting the tile edge
3.Floor ceramic tile edge decoration
4.Anti-slipping for stair nosing
5.Floor dividing line , carpet/floor transition

MOQ 50 M

1.Each with plastic protective film and plastic shrink film for each bundle with customized label+ Plywood case/box/carton,waterproof Kraft paper for each box , customized request available.

2. 20 pieces per bundle, 80-200 per carton
/box for stainless steel packing.

Payment terms 30% deposit, 70% balance before shipment or against B/L copy.
Shipment terms EXW, FOB , CIF

Antifingerprint Aluminium Panel Trim , 3m Aluminium Square Edge Tile Trim 0Antifingerprint Aluminium Panel Trim , 3m Aluminium Square Edge Tile Trim 1
Antifingerprint Aluminium Panel Trim , 3m Aluminium Square Edge Tile Trim 2
